ORBITER MED

E2609 Custom Cushion

Launch Pad Online Quote Request Form

Printable Quote Request Form

LMN Guidelines

Not a clinician? Learn how to get a Kalogon product

When One Seating Approach Isn't Enough

Orbiter Med brings together two components of custom seating:

Individualized Foam Support

The cushion is fabricated around the individual’s measurements and clinical needs.
Its foam structure includes a soft top layer, air cells positioned between the foam layers, a base layer, and a pelvic well.
Clinicians can specify additional supports and modifications based on the user’s presentation.

Advanced Pressure Management System

Strategically positioned air cells work with the Advanced Pressure Management System (APMS) control box.
Machine learning analyzes pressure information and automatically adjusts the air system toward clinician-prescribed levels.
The Kalogon app allows clinicians to configure the system and personalize settings for the individual.

Together, the custom cushion and APMS provide both individualized postural support and adaptive pressure management.

Asymmetry Example

Customize your design for each client based on their needs

Functional Benefits

Depending on the individual’s presentation, clinicians can use Orbiter Med to address:

Pressure Management

Use APMS to establish and maintain prescribed pressure settings
Kalogon’s APMS technology is designed to support tissue revascularization and maintain blood flow in high-risk areas

Individualized Postural Support

Customize the cushion’s shape and supports around the user’s anatomy and positioning needs.

Changing Activities

Create different presets for activities or seating environments that require different pressure-management settings.
Through the Kalogon app, clinicians can create up to 10 personalized presets.
Each preset can establish recommended pressure levels for a specific seating situation.
Once configured, presets can be saved for ongoing use.

Movement Throughout the Day

Allow the system to respond automatically as the user moves, leans, or shifts.
The system responds to movement in real time to help maintain pressure-management settings as the user shifts throughout the day.

Environmental Changes

Ambient sensing allows the air system to respond to changes in environmental pressure and temperature.
The system detects air loss and provides alerts.
If air loss occurs, Orbiter Med can automatically inflate to compensate.
APMS responds to environmental changes, including changes in temperature and pressure, to help maintain prescribed settings.

Complex Custom Seating Situations

Kalogon also works with clinicians on custom seating applications beyond the order form. For more information contact us at 321-465-4504 to get in touch with a representative.

Who May Benefit From Orbiter Med?*

Orbiter Med may be considered for individuals who:

Require a custom wheelchair cushion
Have difficulty or are unable to perform pressure reliefs
Need individualized postural support
Require pressure management in high-risk areas
Experience different seating needs across activities or environments
May benefit from clinician-configured pressure presets
Require extended cushion sizing

*Orbiter Med is a completely custom cushion available by clinician order only and is not sold directly to consumers. It is coded for Medicare reimbursement as E2609. To place an order, a Seating and Mobility Assessment and a completed Order Form from a qualified clinician are required. The Order Form must indicate the patient's specific customization needs. Please note that the customization options listed on this website are not exhaustive — additional customizations may be available.

If you are looking for an intimate fit with targeted postural support, check out Verro: Kalogon's newest E2609 cushion

Specs and Customizations

HCPCS Code E2609
Cushion Sizes 15"–27"
Standard Weight Capacity Up to 300 lbs
Extended Weight Capacity Up to 550 lbs
Optional Gluteal Extension Up to 3"
Approximate Product Weight 5–8 lbs depending on configuration, including control box
Compatible with Manual and Power Wheelchairs
Wheelchair Compatibility for CRT power and manual wheelchairs
Cover – Four-way stretch, water resistant, machine washable
Typical Manufacturing Time 14–21 calendar days, subject to exceptions communicated at time of order
Full-day battery lasts approx 16 hours
Variety of accessories available for even more customization to users needs
Orbiter Med can be configured with options including:
- Posterior Lateral Pelvic Support 1"–3"
- Lateral Thigh Support 1"–3"
- Medial Thigh Support 2"–3" in height and 3"–6" in width
- Pre-Ischial Ridge 1"
- Scrotal Well Up to 6" wide
- Gluteal Extension Up to 3"
- Additional customizations may be available based on the individual’s clinical needs.
